NOTES:

Part #	Number on image	Usage Notes
411-322-050	42	C/W Nyloc Nut

718 - Stealth Original FM 340 - Drive System

Stealth Original FM 340

Grouped product items
No.	Product Name	Price
1	PTO Complete Driveshaft - 540/1000rpm - Trimax Specification 406-340-870 More Info >	A$527.39
2	Bolt - Hex Head - M8 x 16 - Trimax Specification 301-208-163 More Info >	A$0.54
3	Washer - Flat 308-080-016 More Info >	A$0.36
4	Cone 410-440-400 More Info >	A$29.59
5	Gearbox - Standard Rotation - 540rpm 405-200-720 More Info >	A$1,331.62
6	Gearbox 405-200-725 More Info >	A$1,360.08
7	Gearbox - Breather 405-207-207 More Info >	A$31.52
8	Blanking Plug - M12 209-900-012 More Info >	A$0.30
9	Key - Gearbox 405-207-154 More Info >	A$14.95
10	Bolt - Hex Head - M12 x 30 - Trimax Specification 301-212-303 More Info >	A$3.36
11	Washer - Spring M12 - Trimax Specification - 308-120-043 More Info >	A$0.65
12	Pulley - Taper Lock 403-361-270 More Info >	A$283.54
13	Bush - Taper Lock 402-060-680 More Info >	A$99.93
14	Bolt - Hex Head - M8 x 20 - Trimax Specification 301-208-203 More Info >	A$1.31
15	Retainer Ring 402-060-450 More Info >	A$16.34
16	Bush 402-060-320 More Info >	A$26.55
17	Pulley 403-360-300 More Info >	A$64.20
18	Bolt - Hex Head - M8 x 40 - Trimax Specification 301-208-403 More Info >	A$0.47
19	Vee Belt - Trimax Specification 404-040-830 More Info >	A$45.00
20	Vee Belt - Trimax Specification 404-041-300 More Info >	A$53.50
21	Nut - Half 307-212-023 More Info >	A$1.16
22	Belt Retainer Guide 417-330-450 More Info >	A$6.42
23	Pulley Assembly - Idler 403-360-111 More Info >	A$95.00
24	Washer - Flat 108-071-413 More Info >	A$2.89
25	Stud 403-330-443 More Info >	A$2.89
26	Nut - Plain M12 - Trimax Specification - 307-212-013 More Info >	A$0.80
27	Washer - Flat M12 - Trimax Specification - 308-120-013 More Info >	A$0.65
28	Washer - Heavy Flat 308-120-063 More Info >	A$1.65
29	Bolt - Hex Head - M12 x 45 - Trimax Specification 301-212-453 More Info >	A$4.33
30	Idler Tower Incl Base 403-330-442 More Info >	A$78.42
31	Idler Tower Incl Base 403-330-432 More Info >	A$75.39
32	Idler Tower Incl Base 403-330-423 More Info >	A$72.32
33	Idler Tower Incl Base 403-330-424 More Info >	A$53.45
34	Spindle Assembly - Type 5a Ext 50mm 504-328-042 More Info >	A$770.09
35	Spindle Assembly - Type 5b Short Ext 50mm 504-328-043 More Info >	A$1,037.22
36	Nut - Flange 450-000-078 More Info >	A$3.82
37	Bolt - Hex Head - M12 x 50 - Trimax Specification 301-212-503 More Info >	A$4.48
38	Washer - Hardened 108-071-513 More Info >	A$3.54
39	Disc Anti-scalp Rotating - E Type 4 Stud 503-325-475 More Info >	A$271.33
40	Blade Beam - LazerBladez 411-322-762 More Info >	A$77.75
41	Blade - LazerBlade Uplift - Uplift Profile Rotary Cutting Blade 411-160-842 More Info >	A$9.00
42	Blade Bolt - With M12 Nyloc Nut - LazerBlade and NexaBlade Mounting i See notes section for usage notes on this part 411-322-050 More Info >	A$5.00
43	Nut - Nyloc M12 - Trimax Specification - 307-212-053 More Info >	A$1.07
44	Clamp Plate - LazerBladez 411-322-820 More Info >	A$27.37
